DR-680MKII Portable 8-Track Digital Field Recorder

TASCAM premium HDDA (High Definition Discrete Architecture) Mic preamps
Microphone preamps have a significant impact on the quality of the recorded audio. The DR-680MKII has HDDA mic preamps – designed by TASCAM with carefully selected components. Each HDDA mic preamp is built with a differential amplification circuit that employs discrete architecture, and made with parts selected for their audio quality. These preamps also provide +48V phantom power.

8-channels recording at 96kHz/24-bit or 2 tracks at 192kHz/24-bit
In addition to WAV format, this unit also records in BWF format – which stores the recording start times in the metadata. Using the WAV/BWF format, the DR-680KII can record 8 channels at 96kHz/24-bit (6 tracks + stereo track) or 2 tracks at 192kHz/24-bit.

Digital output and 6 unbalanced line outputs
The unit has a built-in coaxial digital input and output (S/PDIF, AES/EBU) and 6 unbalanced line outputs. By connecting a mixer to the outputs, this unit can be used as a 6-track playback device.

Rugged, compact construction
SD, SDHC and SDXC cards are used as recording and playback media, and the compact form offers excellent vibration resistance. Along with the included shoulder strap, this unit has a built-in folding stand for tabletop use, making operation easy in a variety of situations.

Sampling frequencies:

• 44.1, 48, 96, 192 kHz (BWF, WAV) 44.1, 48 kHz (MP3)
• Quantization bit depth: 16/24-bit (BWF, WAV)

Features:

• 8-track recording at 24-bit/96kHz (BWF, WAV)
• 2-track recording at 24-bit/192kHz (BWF, WAV)
• SD/SDHC/SDXC cards used as recording/playback media
• 6 balanced mic/line inputs (1-4: XLR/TRS combo jacks, 5-6: TRS jacks)
• 6 unbalanced outputs (RCA pin jacks)
• COAXIAL digital input and output (S/PDIF, AES/EBU)
• Recording/playback formats: BWF, WAV, MP3
• With BWF format, recording starting times can be stored in files
• 6 mic/line inputs and stereo mix recording or 6 mic/line input and digital stereo recording
• Record MP3 files at 96, 128, 192 and 320 kbps
• Digital inputs and outputs support double speed 96 kHz and quad speed 192 kHz

Get your today Tascam DR-680MKII at the guaranteed lowest price

Made in China
