SM Pro Audio Q-Pre 4-Channel Microphone Preamp – Open Box B Stock

Buy SM Pro Audio Q-Pre 4-Channel Microphone Preamp online in India – India’s music equipment superstore.

SM Pro Audio Q-Pre 4-Channel Microphone Preamp – Open Box B Stock Overview:

Open Box Gear are products returned by customers, and are inspected and certified by to be in full working order. Products may have minor scratches, dents, missing or damaged original box, or missing manuals, cables or accessories. Please review each product’s specific condition listed below. All Open Box sales are final.

Open Box deals are great for those willing to overlook minor cosmetic flaws, for a fully functional product at a discounted price

#19196

Condition: Box & Adapter missing, Scratch marks on unit

The 4-Channel SM Pro Audio Q-Pre Microphone Preamp is for budget-conscious studios, yet it also works well in live environments as well. With systems available at very low prices, the market size for digital audio interfaces and computer-based digital editing has increased in a massive way. One of the main problems with many of these systems is the input stage only consists of unbalanced line inputs or very low (or no mic pre) gain structure for the balanced input stage and the unavailability of phantom power.

The SM Pro Audio Q-Pre comes to the rescue with 4 mic preamps, balanced input, gain control from -20dB to +40dB, and phantom power switchable for channels 1/2 & 3/4 (in pairs). The Q-Pre preamp uses SM Pro Audio’s well-established E-Series mic preamps, enhanced circuit design, and robust housing, which can be rack mounted on an optional rack tray.

SM Pro Audio Q-Pre 4-Channel Features:

• Four totally independent preamplifiers in a half-rack package
• High-quality audio
• 4 x balanced inputs
• 4 x unbalanced outputs
• Phantom on/off per 2-channel pairs
• 4 x peak indicators
• Individual gain control on each channel.

SM Pro Audio Q-Pre 4-Channel Specifications:

Audio Inputs:

• Connectors: 1/4″ jack
• Type: balanced
• Impedance: 2KOhms
• Min Sensitivity: -40dB
• Peak input level: +5dB
• Gain control range: 50dB
• Peak amplification: 74dB
• Phantom power: +48V, switchable.

Audio Outputs:

• Connectors: 1/4″ jack
• Type: TRS balanced
• Impedance: -10dB 47k
• Peak output level: +18.5dB
• Dist, Freq, S/N Ratio & Crosstalk:
• Frequency response: 20Hz~20kHz, 0dB~-2B
• Distortion: 0.02%
• S/N Ratio: better than 80dB
• Crosstalk rejection: >70dB@1kHz;-20dB input.

Power Supply:

• Mains voltages: USA/Canada ~ 120 V AC, 60Hz
• Power consumption: 8.5VA
• Fuse: 100-120V AC: 315mA (slow-blow), 200-240 V AC: 315mA (slow-blow)
• Mains connection: Using External Power Supply 16Vac.

Others:

• Dimensions: (HxWxD) 1-3/4″ (44.5mm) x 19″ (482.6mm) x 8 1/2″ (217mm)
• Net weight: approx. 3.4kg.
