Zoom F2 Field Recorder and Lavalier Microphone

Zoom F2 Field Recorder and Lavalier Microphone Overview:

For podcasters, videographers, bloggers, journalists and more, the F2 is the perfect audio solution for creators on the move.

DONT BE FOOLED BY ITS SIZE
The F2 is incredibly small, but its audio quality will amaze you.

AUDIO ON AUTOPILOT
The F2 features 32-bit float recording technology, allowing you to record the loudest audio signals without worrying about clipping. It will also record the quietest signals in beautiful detail. And the best part is you dont have to worry about setting the gain. Just plug in the lav and hit record.

Once you start your recording, use the F2s HOLD switch to ensure you dont accidentally stop recording

LOCK N LAV
Screw-lock connectors keep your lav plugged-in securely no matter the situation.

THE F2 EDITOR
The F2 Editor for PC and Mac allows you to adjust settings, format SD cards and more. Simply connect your F2 or F2-BT via a USB cable and launch the editor. The USB connection also makes it easy to transfer files to your computer. See the F2 Editor features here.

Features:

• Light and compact audio recorder
• 32-Bit Float recording for full dynamic range and clip free recording
• No gain adjustment necessary
• Records 44.1kHz/32-bit float or 48kHz/32-bit float audio files
• Rec Hold function to avoid accidental operation of buttons
• 1/8″ Mic In mini phone jack with Plug-in power (2.5V)
• Stere
• Stereo ” Phone/Line Output jack with dedicated volume control
• 80 Hz low cut filter
• High precision internal clock to avoid audio and video syncing issues
• Wireless timecode synchronization (F2-BT model only)*
• Records directly to micro SD, SDHC, and SDXC cards up to 512 GB
• USB-C for connection to F2 Editor for settings
• Built-in Bluetooth for connection to the F2 Control app for settings adjustment and remote transport control (F2-BT model only)
• Runs on only 2 standard AAA alkaline, Lithium, or NiMH rechargeable batteries, or AC adapter (AD-17)
• Up to 15 hours of operation (14 hours on the F2-BT) with two AAA alkaline batteries

Specifications:

INPUT

• CONNECTOR: 3.5 mm stereo mini (with screw lock) Supports plug-in power (2.5 V)
• INPUT GAIN: None (dual AD conversion system)
• INPUT IMPEDANCE: 2 k or more
• MAXIMUM INPUT LEVEL: 5.5 dBu

OUTPUT

• CONNECTOR: 3.5 mm stereo mini (with screw lock)
• MAXIMUM OUTPUT LEVEL: 20 mW + 20 mW (into 32 load)

RECORDING MEDIA

• CARDS COMPATIBLE WITH MICROSD/MICROSDHC/MICROSDXC SPECIFICATIONS (CLASS 4 OR HIGHER, 512 GB MAXIMUM)

RECORDING FORMAT

• WAV: 44.1kHz/32-bit float, 48kHz/32-bit float Mono, BWF format supported

USB

• USB TYPE-C
• MASS STORAGE OPERATION USB 2.0 High Speed
• PC APP OPERATION USB 2.0 High Speed

POWER

• 2 AAA BATTERIES (ALKALINE, LITHIUM OR RECHARGEABLE NIMH BATTERIES) AC ADAPTER (ZOOM AD-17): DC 5 V/1 A

MISCELLANEOUS

• BLUETOOTH: Bluetooth Ver4.2 (F2-BT only)
• CONTINUOUS RECORDING TIME WHEN USING LAVALIER MIC (48KHZ/32-BIT FLOAT): Alkaline batteries: about 14 hours
• NiMH batteries (750 mAh): about 10 hours Lithium batteries: about 18 hours
• The above values are approximate.
• EXTERNAL DIMENSIONS: 57.5 mm (W) 46.4 mm (H) 22.4 mm (D)
• WEIGHT (MAIN UNIT ONLY): 32 g

LMF-2

• LAVALIER MIC
• CONNECTOR: 3.5 mm stereo mini (with screw lock)
• DIRECTIONALITY: Omnidirectional
• SENSITIVITY: 32 dB/Pa at 1 kHz
• MAXIMUM SOUND PRESSURE INPUT: 115 dB SPL
• CABLE LENGTH: 160 cm
